Product Summary

The LM556CN is a Dual timing circuit which is a highly stable controller capable of producing accurate time delays or oscillation. Timing is provided by an external resistor and capacitor for each timing function. The LM556CN operates independently of each other sharing only VCC and ground. The circuit may be triggered and reset on falling waveforms. The output structures may sink or source 200mA. Applications include: Precision timing, Pulse generation, Sequential timing, Time delay generation, Pulse width modulation, Pulse position modulation and Linear ramp generator

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LM556CN
LM556CN

National Semiconductor (TI)

Timers & Support Products

Data Sheet

0-750: $0.59
750-1000: $0.47
1000-2500: $0.44
2500-5000: $0.41
LM556CN/NOPB
LM556CN/NOPB

National Semiconductor (TI)

Timers & Support Products DUAL TIMER

Data Sheet

0-1: $0.86
1-25: $0.68
25-100: $0.59
100-250: $0.53
